Description
Key Features
? 384 × 288 resolution, 12 µm, high sensitivity detector
? Adaptive AGC, DDE, 3D DNR, NETD less than 35 mk (@25°C), F#=1.0
? 1280 × 960 resolution 0.4-inch LCOS display
? Built-in rechargeable lithium battery
? Up to 7.5 hours continuous running
? Wi-Fi hot spot
? Type-C Interface
Specification
Thermal Module
Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution 384 × 288
Pixel Interval 12 µm
Response Waveband 8 µm to 14 µm
NETD less than 35 mk (@25°C), F#=1.0
Lens (Focal Length) 25 mm
Field of View 10.5° × 7.9° (H × V)
Digital Zoom 1 ×, 2 ×, 4 ×, 8 ×
Aperture F1.0
Magnification 2.45 to 19.6
Image Display
Monitor 0.4 inch, LCOS, 1280 × 960
FFC (Flat Field Correction) Auto, Manual, External Correction
Palettes Black Hot, White Hot, Red Hot, Fusion
Frame Frequency 50 Hz
Smart Function
Wi-Fi Hot Spot Yes
Standby Mode Yes
Detection Range 1180 m
System
Storage Built-in memory module (8 GB)
Record Video Yes
Capture Snapshot Yes
Power Supply
Battery Type Lithium battery
Battery Operating Time
7.5 hours continuous running with Wi-Fi hot spot function off (@25°C)
6 hours continuous running with Wi-Fi hot spot function on (@25°C)
Battery Capacity Display Yes
General
Power 5 VDC/2 A, 1.5 W, Type-C Interface
Working Temperature -20 °C to 55 °C (-4 °F to 131 °F)
Protection Level IP67
Dimension 171 mm × 61 mm × 57 mm (6.73" × 2.40" × 2.24")
Weight 300 g (0.66 lb
