Pilot Cut Gen2 – a new type of 2-blade or 4-blade interchangeable broadhead Assembly Instructions – 6 easy steps – Infill or Bleeder Blade
1. Select either Infill or Bleeder Blade (Note: if choosing Bleeder Blade please use a small pair of pliers to prevent injury.) 2. Apply a small amount of string wax on the thread and shank of the broadhead (This helps with seating the Infill/Bleeder Blade & helps tighten the washer.)
3. Install the front of the Infill/Bleeder Blade into the slot ensuring you keep it centred. (The front is identified by the small round hole.)
4. Push the back of the Infill/Bleeder Blade in until the rear locating tabs are flush with the shank of the broadhead.
5. Install washer over thread onto the shank of the broadhead, securing the locating tabs. (Take care as there are multiple cutting edges. Please use a broadhead wrench to prevent injury and to ensure maximum tightness.)
6. Screw into your arrow Please check out our YouTube Channel for our instructional video.

*Note: The Bleeder Blade adds 5-10 grains of weight to the Broadhead system

*Please make sure to tune your broadheads and bow prior to going out hunting

Aerodynamic design
Full stainless steel construction
3:1 Ratio at front
Solid one piece
Single bevel.
True 46-48 Rockwell Hardness
